viii
H81-PLUS specifications summary
Rear panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x RGB port
1 x LAN (RJ-45) port
2 x USB 3.0/2.0 ports (blue)
2 x USB 2.0/1.1 ports
1 x COM port
1 x LPT port
3 x Audio jacks support 8-channel audio output
Internal
connectors/
switches/
buttons
3 x USB 2.0/1.1 connectors support additional 6 USB 2.0 ports
2 x SATA 6.0 Gb/s connectors
2 x SATA 3.0 Gb/s connectors
1 x CLRTC jumper
1 x 4-pin CPU fan connector
1 x 4-pin Chassis fan connectors
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x S/PDIF Header
1 x 24-pin EATX power connector
1 x 4-pin EATX 12V power connector
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS v2.7, ACPI
v4.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My
Favorites, Quick Note, Last Modied log, F12 PrintScreen, F3 Shortcut functions
Manageability
WfM 2.0, DMI 2.0, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Operating
System
Support
Windows
®
8 / Windows
®
7
Form factor
ATX form factor: 12.0”x 7.4” (30.5cm x 18.8cm)
Specications are subject to change without notice.
