Storage
Intel
®
Z97 Express Chipset:
6 x SATA 6 Gb/s ports*
- Intel
®
Rapid Storage Technology 13 supports RAID 0, 1, 5,
and 10
- Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology, and Intel
®
Smart Connect Technology*
1 x M.2 Socket 3 with M Key, type 2260/2280 storage devices
support**
* The supported functions depend on the CPU installed.
** Supports PCIe interface only.
LAN
1 x Intel
®
I218-V Gigabit LAN
Anti-surge Ethernet port
ROG GameFirst III
Audio
ROG SupremeFX Audio 8-Channel High Definition
Audio
- SupremeFX Shielding Technology
- ELNA
®
Premium Audio Capacitors
- Content Protection for Full Rate lossless DVD Audio, Blu-ray
DVD, and HD-DVD audio content playback
- Jack-detection, Multi-streaming, Front Panel Jack-retasking,
Gold Plated Audio Jacks
- Optical S/PDIF out port at back panel
Audio Feature:
- Sonic Radar II
- Sonic Studio
- Sonic SoundStage
- Sonic SenseAmp
- DTS Connect
USB
Intel
®
Z97 Express Chipset
6 x USB 3.0 ports (4 ports at back panel [blue], 2 ports at mid-board
[red])*
7 x USB 2.0 ports (2 ports at back panel, 5 ports at mid-board)**
* Supports ASUS USB 3.0 Boost, UASP standard on the Intel
®
native
USB 3.0 is only supported under Windows
®
8 / 8.1.
** 1 x USB 2.0 port (USB13) shares with ROG extension (ROG_EXT) port.
Back I/O Ports
1 x PS/2 keyboard/mouse combo port
2 x USB 2.0 ports
1 x USB BIOS Flashback button
1 x Optical S/PDIF out
1 x HDMI port
1 x RGB (VGA) port
1 x DVI-D (DVI) port
4 x USB 3.0 ports [blue]
1 x Anti-surge LAN (RJ45) port
6 x 8-channel golden plated audio jacks
MAXIMUS VII RANGER specifications summary
