Asus rog maximus vii ranger [182/200] Chapter 4

4-40

Chapter 4: Software support

Chapter 4

Synchronizing backup files

Aftercreatingajunctionpoint,RAMDiskautomaticallycreatesabackupfolderinthele’s

originallocation.UseRAMDisktomanuallysynchronizeupdateswiththesebackuples.

Click Synchronize to

update your files
