3-14
Chapter 3: BIOS setup
Chapter 3
MCH Full Check [Auto]
Enable this item to enhance the stability of your system. Disable this item to enhance
the DRAM overclocking capability. Conguration options: [Auto] [Enabled] [Disabled]
DQ Sense Amplifier [Auto]
Reducing usually helps overclocking and over-voltage.
Conguration options: [Auto] [+16] – [-29]
DQS Sense Amplifier [Auto]
Reducing usually helps overclocking and over-voltage. Conguration options: [Auto]
[+16] – [-29]
CMD Sense Amplifier [Auto]
Reducing usually helps overclocking and over-voltage. Conguration options: [Auto]
[+16] – [-29]
DRAM Additional Training [Auto]
Reducing usually helps overclocking and over-voltage. Conguration options: [Auto]
[Enabled] [Disabled]
Skew Control
Transmitter Rising Slope [Auto]
Conguration options: [Auto]
Transmitter Falling Slope [Auto]
Conguration options: [Auto]
Transmitter Control Time [Auto]
Conguration options: [Auto]
Receiver Rising Slope [Auto]
Conguration options: [Auto]
Receiver Falling Slope [Auto]
Conguration options: [Auto]
Receiver Control Time [Auto]
Conguration options: [Auto]
GPU.DIMM Post
Automatically detects and displays the information about the devices or memory installed on
the PCIe and DIMM slots. The eld shows N/A if there are no devices installed on the slots.
