Asus h81m2 [13/75] Cpu heatsink and fan assembly installation
![Asus h81m2 [13/75] Cpu heatsink and fan assembly installation](/views2/1159759/page13/bgd.png)
ASUS H81M2
1-5
A
B
C
5
4
1.3.2 CPU heatsink and fan assembly installation
Apply the Thermal Interface Material
to the CPU heatsink and CPU
before you install the heatsink and
fan if necessary.
