ASUS H81M2

2-21

2.5.16 CPU Analog I/O Voltage Offset Mode Sign [+]

This item allows you to set the CPU analog I/O voltage offset mode sign. Conguration

options: [+] [-].

CPU Analog I/O Voltage Offset [Auto]

This item allows you to set the CPU analog I/O voltage offset. Increase the value when

increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.

2.5.17 CPU Digital I/O Voltage Offset Mode Sign [+]

This item allows you to set the CPU digital I/O voltage offset mode sign. Conguration

options: [+] [-].

CPU Digital I/O Voltage Offset [Auto]

This item allows you to set the CPU digital I/O voltage offset. Increase the value when

increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.

2.5.18 SVID Control [Auto]

Disabling SVID Support stops the processor from commmunicating with the external voltage

regulator. Conguration options: [Auto] [Disabled] [Enabled].

• We recommend that you disable this function when overclocking.

• The following item appears only when you set SVID Support to

[Enabled].

SVID Voltage Override [Auto]

Allows you to set the SVID Voltage override. Use the <+> or <-> keys to adjust the

value. The values range from 0.001V to 2.440V with a 0.001V interval.

2.5.19 DRAM Voltage [Auto]

Allows you to set the DRAM Voltage. The values range from 1.500V to 1.650V with a 0.05V

interval.

According to Intel CPU specications, DIMMs with voltage requirement over 1.65V may

damage the CPU permanently. We recommend that you install the DIMMs with the voltage

requirement below 1.65V.
