viii
H81M2 specications summary
Internal
connectors
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
1 x USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports
2 x SATA 6.0 Gb/s connectors
2 x SATA 3.0 Gb/s connectors
1 x 4-pin CPU fan connector
1 x 4-pin Chassis fan connector
1 x Front panel audio connector
1 x COM Header
1 x LPT Header
1 x TPM Header
1 x 24-pin ATX power connector
1 x 4-pin ATX 12V power connector
1 x Speaker connector
1 x System panel connector
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS 2.6,
ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFreen BIOS
3, F12 Printscreen function, F3 Shortcut function and ASUS DRAM SPD (Serial
Presence Detect) memory information
Manageability
WfM 2.0, DMI 2.0, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Operating
System
Support
Windows
®
8
Windows
®
7
Form factor
uATX form factor: 9.6”x 7.8” (24.4cm x 19.8cm)
Specications are subject to change without notice.
