ASUS M5A97 PLUS

2-23

2.5.7 APM

Restore AC Power Loss [Power Off]

[Power On] The system goes into on state after an AC power loss.

[Power Off] The system goes into off state after an AC power loss.

[Last State] The system goes into either off or on state, whatever the system state was

before the AC power loss.

Power On By PS/2 Device [Disabled]

Allows you to use PS/2 device to turn on the system. This feature requires an ATX power

supply that provides at least 1A on the +5VSB lead. Conguration options: [Disabled]

[Enabled]

Power On By PME Device [Disabled]

[Disabled] Disables the PME to wake up from S5 by PCI/PCIE devices.

[Enabled] Allows you to turn on the system through a PCI/PCIE LAN or modem card.

This feature requires an ATX power supply that provides at least 1A on the

+5VSB lead.

Power On By Ring [Disabled]

[Disabled] Disables to power up the computer when the external modem receives a

call while the computer is in Soft‑off mode.

[Enabled] The computer could be powered up when the external modem receives a

call while the computer is in Soft‑off mode.

The computer cannot receive or transmit data until the computer and applications are fully

running. Thus, connection cannot be made on the rst try. Turning an external modem

off and then back on while the computer is off causes an initialization string that turns the

system power on.

Power On By RTC [Disabled]

[Disabled] Disables RTC to generate a wake event.

[Enabled] When set to [Enabled], the items RTC Alarm Date (Days) and System

Time will become user‑congurable with set values.

SPDIF Out Type [SPDIF]

[SPDIF] Sets to [SPDIF] for SPDIF audio output.

[HDMI] Sets to [HDMI] for HDMI audio output.
