xii
ASUS Special Features
ASUS 5X Protection:
- ASUS DIGI+ VRM - 8 Phase digital power design
- ASUS Enhanced DRAM Overcurrent Protection - Short circuit
damage prevention
- ASUS ESD Guards - Enhanced ESD protection
- ASUS High-quality 5K-Hour Solid Capacitors - 2.5x long
lifespan with excellent durability
- ASUS Stainless Steel rear I/O - 3x more durable corrosion-
resistant coating
USB 3.1 Boost
USB Charger+
Ai Charger+
Disk Unlocker
Ai Suite 3
MemOK!
EZ XMP
ASUS Quiet Thermal
Solution
Quiet Thermal Design
- ASUS Fan Xpert 3
- ASUS Fanless Design: Heatsink solution with the aesthetic
streamline I/O cover
ASUS Exclusive
Overclocking Features
Precision Tweaker 2
- vCore: Adjustable CPU Core voltage at 0.001 V increment
- iGPU: Adjustable CPU Graphics voltage at 0.001 V increment
- vCCIO: Adjustable Analog and Digital I/O voltage at 0.001 V
increment
- vCCIN: Adjustable CPU Input voltage at 0.01 V increment
- vCCSA: Adjustable CPU System Agent voltage at 0.001 V
increment
- vDRAM Bus: 110-step Memory voltage control
- vPCH: 176-step Chipset voltage control
SFS (Stepless Frequency Selection)
- BCLK/PCIE frequency tuning from 80 MHz to 300 MHz at 0.1
MHz increment.
Overclocking Protection
- ASUS C.P.R. (CPU Parameter Recall)
Rear Panel I/O Ports
1 x BIOS Flashback button
1 x Optical S/PDIF Out port
1 x Intel
®
LAN (RJ45) port
2 x USB 3.1/3.0/2.0 ports (teal blue)
4 x USB 3.0/2.0 ports (blue)
4 x USB 2.0/1.1 ports (bottom port supports USB BIOS Flashback)
1 x Keyboard/Mouse combo connector
8-channel Audio I/O ports
Internal I/O Connectors
2 x 19-pin USB 3.0/2.0 connectors, support additional 4 USB ports
1 x M.2 Socket 3 with M Key design, type 2242/2260/2280/22110
storage devices support (supports PCIE SSD only)
X99-A/USB 3.1 specifications summary
(continued on the next page)
