Asus x99-a/usb 3.1 [83/148] Qfan control

ASUS X99-A/USB 3.1

3-7

Chapter 3

3.2.3 QFan Control

The QFan Control allows you to set a fan prole or manually congure the operating speed of

your CPU and chassis fans.

Click to select a fan to be

configured

Click to activate

PWM Mode

Click to undo the

changes

Click to apply the fan setting

Click to go back to main menu

Select a profile to apply to

your fans

Click to activate DC Mode

Select to manually configure

your fans
