P9X79 LE specications summary
ASUS exclusive
overclocking features
Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.005V increment
- vTTCPU: Adjustable I/O voltage at 0.00625V increment
- vCCSA: 255-step system agent voltage control
- vDRAM Bus: 160-step Memory voltage control
- vPCH: 96-step Chipset voltage control
- vCPU_PLL: 48-step CPU & PCH PLL voltage control
SFS (Stepless Frequency Selection):
- BCLK/PEG frequency tuning from 80MHz up to 300MHz at
0.1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
ASUS Unique Features ASUS Dual Intelligent Processors 3
with New DIGI+ Power Control:
CPU Power
- Industry leading Digital 6+2 Phase Power Design
- CPU Power Utility
DRAM Power
- Industry leading Digital 2+2 Phase Power Design
- DRAM Power Utility
ASUS TPU
- Auto Tuning, TurboV
ASUS EPU
- EPU Utility
ASUS Exclusive Features:
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user
interface
- USB 3.0 Boost
- MemOK!
- Remote GO!
- AI Suite II
- Ai Charger
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Stylish Heat-sink solution
- ASUS Fan Xpert+
ASUS EZ DIY:
- USB BIOS Flashback with USB BIOS Flashback Wizard for
EZ BIOS download scheduling
- ASUS O.C. Prole
- ASUS MyLogo 2
- Percision Tweaker 2
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- DirectKey
- Multi-language BIOS
ASUS Q-Design:
- ASUS Q-Shield
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Connector
(continued on the next page)
