Asus P9X79 LE [165/176] Chapter 5
![Asus P9X79 LE [165/176] Chapter 5](/views2/1163301/page165/bga5.png)
ASUS P9X79 LE 5-5
Chapter 5
1
Enabling Dual CrossFireX technology
1. In the Catalyst Control Center window, click Performance > AMD CrossFireX
TM
.
2. Select
Enable CrossFireX
TM
.
3. Select a GPU combination from the drop-down list.
4. Click
Apply to save and activate the GPU settings made.
2
3
4
