Asus TUF SABERTOOTH X79 [47/148] Cpu heatsink and fan assembly installation

ASUS SABERTOOTH X79 2-29

Chapter 2

2.3.3 CPU heatsink and fan assembly installation

Apply the Thermal Interface Material

to the CPU heatsink and CPU

before you install the heatsink and

fan if necessary.

To install the CPU heatsink and fan assembly

1 2

++E8040_SABERTOOTH_X79_V3.indb 29 21/1/13 5:35:21 PM
