Beko cwb 9730 x [4/56] English

- 4 -

ENGLISH

GENERAL

Carefully read the following important information regarding

installation safety and maintenance. Keep this information

booklet accessible for further consultations.

The appliance has been designed for use in the ducting

version (air exhaust to the outside – Fig.1B),  ltering version

(air circulation on the inside – Fig.1A) or with external motor

(Fig.1C).

SAFETY PRECAUTION

1. Take care when the cooker hood is operating simultane-

ously with an open  replace or burner that depend on the air

in the environment and are supplied by other than electrical

energy, as the cooker hood removes the air from the environ-

ment which a burner or  replace need for combustion. The

negative pressure in the environment must not exceed 4Pa

(4x10-5 bar). Provide adequate ventilation in the environment

for a safe operation of the cooker hood.

Follow the local laws applicable for external air evacuation.

Before connecting the model to the electricity network:

- control the data plate (positioned inside the appliance)

to ascertain that the voltage and power correspond to the

network and the socket is suitable. If in doubt ask a quali ed

electrician.

- If the power supply cable is damaged, it must be replaced

with another cable or a special assembly, which may be

obtained direct from the manufacturer or from the Technical

Assistance Centre.

- This device must be connected to the supply network

through eiter a plug fused 3A or hardwired to a 2 fase spur

protected by 3A fuse.

2. Warning !

In certain circumstances electrical appliances may be a

danger hazard.

A) Do not check the status of the filters while the cooker

hood is operating

B) Do not touch bulbs or adjacent areas, during or straight

after prolonged use of the lighting installation.

C) Flambè cooking is prohibited underneath the cooker

hood

D) Avoid free flame, as it is damaging for the filters and

a fire hazard

E) Constantly check food frying to avoid that the

overheated oil may become a fire hazard

F) Disconnect the electrical plug prior to any

maintenance.

G) This appliance is not intended for use by young children

or infirm persons without supervision

H) Young children should be supervised to ensure they

do not play with the appliance

I) There shall be adequate ventilation of the room when

the rangehood is used at the same time as appliances

burning gas or other fuels

L) There is a risk of fire if cleaning is not carried out in

accordance with the instructions

This appliance conforms to the European Directive EC/2002/96,

Waste Electrical and Electronic Equipment (WEEE). By making

sure that this appliance is disposed of in a suitable manner,

the user is helping to prevent potential damage to the

environment or to public health.

The

symbol on the product or on the accompanying

paperwork indicates that the appliance should not be treated

as domestic waste, but should be delivered to a suitable

electric and electronic appliance recycling collection point.

Follow local guidelines when disposing of waste. For more

information on the treatment, re-use and recycling of this

product, please contact your local authority, domestic waste

collection service or the shop where the appliance was

purchased.

INSTALLATION INSTRUCTIONS

Assembly and electrical connections must be carried out

by specialised personnel.

• Electric Connection

The appliance has been manufactured as a class II, therefore

no earth cable is necessary.

The connection to the mains is carried out as follows:

BROWN = L line

BLUE = N neutral

If not provided, connect a plug for the electrical load indi-

cated on the description label. Where a plug is provided, the

cooker hood must be installed in order that the plug is easily

accessible. An omnipolar switch with a minimum opening of

3mm between contacts, in line with the electrical load and

local standards, must be placed between the appliance and

the network in the case of direct connection to the electrical

network.

Warning:

When connecting the appliance to the electricity supply, make

sure that the mains socket has an earth connection.

After  tting the ducted cooker hood, make sure that the

electrical plug is in a position where it can be accessed easily.

If the appliance is connected directly to the electricity supply,

an omnipolar switch with a minimum contact opening of

3 mm must be placed in between the two; its size must

be suitable for the load required and it must comply with

current legislation.

• The minimum distance between the support surfaces of

the cooking pots on the cooker top and the lowest part of

the cooker hood must be at least 65 cm. If a connection tube

composed of two parts is used, the upper part must be placed

outside the lower part. Do not connect the cooker hood ex-

haust to the same conductor used to circulate hot air or for

evacuating fumes from other appliances generated by other

than an electrical source. Before proceeding with the assembly

operations, remove the anti-grease  lter(s) (Fig.5) so that the

unit is easier to handle.

In the case of assembly of the appliance in the suction version

prepare the hole for evacuation of the air.

• We recommend the use of an air exhaust pipe with a

diameter of 150. If a pipe with a smaller diameter is used, the

e ciency of the product may be reduced and its operation

may become noisier.

• Fixing to the wall

Drill the holes A respecting the distances indicated (Fig.2). Fix

the appliance to the wall and align it in horizontal position

to the wall units. When the appliance has been adjusted,

Beko cwb 9730 x [4/56] English
