- 5 -

de nitely  x the hood using the screws A (Fig.4). For the

various installations use screws and screw anchors suited to

the type of wall (e.g. reinforced concrete, plasterboard, etc.). If

the screws and screw anchors are provided with the product,

check that they are suitable for the type of wall on which the

hood is to be  xed.

• Fixing the decorative telescopic  ue

Arrange the electrical power supply within the dimensions

of the decorative  ue. If your appliance is to be installed in

the ducting version or in the version with external motor,

prepare the air exhaust opening. Adjust the width of the

support bracket of the upper  ue (Fig.3). Then  x it to the

ceiling using the screws A (Fig.3) in such a way that it is in line

with your hood and respecting the distance from the ceiling

indicated in Fig.2. Connect the  ange C to the air exhaust hole

using a connection pipe (Fig.4). Insert the upper  ue into the

lower  ue. Fix the lower  ue to the hood using the screws B

provided (Fig.4), extract the upper  ue up to the bracket and

 x it with the screws B (Fig.3).

To transform the hood from a ducting version into a  ltering

version, ask your dealer for the charcoal  lters and follow the

installation instructions.

• Filtering version

Install the hood and the two  ues as described in the para-

graph for installation of the hood in ducting version. To as-

semble the  ltering  ue refer to the instructions contained

in the kit. If the kit is not provided, order it from your dealer

as accessory. The  lters must be applied to the suction unit

positioned inside the hood. They must be centred by turning

them 90 degrees until the stop catch is tripped (Fig.6).

USE AND MAINTENANCE

• We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance

is left running for 15 minutes after the food is cooked, in

order to thoroughly eliminate all contaminated air.

The e ective performance of the cooker hood depends on

constant maintenance; the anti-grease  lter and the active

carbon  lter both require special attention.

• The anti-grease  lter is used to trap any grease particles

suspended in the air, therefore is subject to saturation (the

time it takes for the  lter to become saturated depends on

the way in which the appliance is used).

- To prevent potential  re hazards, the anti-grease  lters

should be washed a minimum of every 2 months (it is

possible to use the dishwasher for this task).

- After a few washes, the colour of the  lters may change.

This does not mean they have to be replaced.

If the replacement and washing instructions are not followed,

the anti-grease  lters may present a  re hazard.

• The active carbon  lters are used to purify the air which

is released back into the room. The  lters are not washable

or re-usable and must be replaced at least once every four

months. The active carbon  lter saturation level depends on

the frequency with which the appliance is used, the type of

cooking performed and the regularity with which the anti-

grease  lters are cleaned.

• Clean the cooker hood frequently, both inside and outside,

using a cloth which has been dampened with denatured

alcohol or neutral, non-abrasive liquid detergents.

• The light on the cooker hood is designed for use during

cooking and not for general room illumination. Extended

use of the light reduces the average duration of the bulb.

• Replacing halogen light bulbs( g.7).

To replace the halogen light bulbs B, remove the glass pane

C using a lever action on the relevant cracks.

Replace the bulbs with new ones of the same type.

Caution: do not touch the light bulb with bare hands.

•Commands: (fig.8) mechanical the key symbols are ex-

plained below:

A = LIGHT

B = OFF

C = SPEED I

D = SPEED II

E = SPEED III

• Commands: ( g.9) luminous the key symbols are explained

below:

A = LIGHT

B = OFF

C = SPEED I

D = SPEED II

E = SPEED III

F = AUTOMATIC STOP TIMER - 15 minutes (*)

• If your appliance does not have the INTENSIVE speed

function, press key E for two seconds and it will be activated

for 10 minutes after which it will return to the previously set

speed. When the function is active the LED  ashes. To interrupt

it before the 10 minutes have expired press key E again.

• By pressing key F for two seconds (with the hood switched

o ) the “clean air” function is activated. This function switches

the appliance on for ten minutes every hour at the  rst speed.

As soon as this function is activated the motor starts up at the

 rst speed for ten minutes, During this time key F and key

C must  ash at the same time. After ten minutes the motor

switches o and the LED of key F remains switched on with

a  xed light until the motor starts up again at the  rst speed

after  fty minutes and keys F and C start to  ash again for ten

minutes and so on. By pressing any key for the exclusion of

the hood light the hood will return immediately to its normal

functioning (e.g. if key D is pressed the “clean air” function is

deactivated and the motor moves to the 2nd speed straight

away. By pressing key B the function is deactivated).

(*) The “automatic stop timer” delays stopping of the hood,

which will continue functioning for 15 minutes at the operat-

ing speed set at the time this function is activated.

• Active carbon/grease  lter saturation:

- When button A  ashes at a frequency of 2 seconds, the

grease  lters must be cleaned.

- When button A  ashes at a frequency of 0.5 seconds, the

carbon  lters must be replaced.

After the clean  lter has been replaced, the electronic memory

must be reset by pressing button A for approximately 5

seconds, until the light on the button stops  ashing.

• Commands: ( g.10).

Push-button A = on/o lights switch

Push-button B = on/o cooker hood switch. The appliance

switches on at speed level 1, If the cooker hood is on depress

the push-button for 2 sec. to switch o the cooker hood. If

the cooker hood is at speed level 1 it will not be necessary

to depress the push-button to switch the cooker hood o .

Decreases the motor speed.

Display C = indicates the motor speed level selected and

activates the timer.
