Changing the aspect for computer images
You can change the Aspect as follows. This projector offers WXGA 1280x800 resolution (Aspect Ratio 16:10). When projecting onto 16:9 screens, set the
Aspect to 16:9.
Set Values Operation Projection example
Normal
Projects to the full projection size retaining the Aspect of
the input image.
When a 1024x768 signal is input
Auto
Displayed only when the source is
HDMI.
Projects in an appropriate aspect based on information
from the input signal.
16:9
Projects to the full projection size at an Aspect of 16:9. When a 1024x768 signal is input
Full
Project at full size. When a 1024x768 signal is input
Functions for Enhancing Projection
19
