Extended Menu
Sub Menu Function
Display
You can make settings related to the projector's display.
Messages: When set to Off, the following items will not be displayed. The name of the current selection when changing the Source,
Color Mode or Aspect; a message when no image signal is input; warnings such as the High Temp Warning.
Display Background: You can set the screen status for when no image signal is available to Black, Blue, or Logo.
Startup Screen: You can set whether or not (On/Off) the Startup Screen (the image projected when starting the projector) is displayed.
A/V Mute: You can set the screen displayed during A/V Mute as Black, Blue, or Logo.
User's Logo
You can change the User's Logo that is displayed as a background during Display Background, A/V Mute, and so on.s p.62
Projection
You can set from the following according to the way the projector is setup.s p.52
Front, Front/Ceiling, Rear, Rear/Ceiling
You can change the setting as follows by pressing down the [A/V Mute] button on the Remote Control for about five seconds.
Front
W
Front/Ceiling
RearWRear/Ceiling
List of Functions
35
