About Your Monitor 19
Resolution Specifications
Model number Dell E1914H monitor Dell E2014H monitor
Scan range
• Horizontal 30 kHz to 83 kHz (automatic) 30 kHz to 83 kHz (automatic)
• Vertical 56 Hz to 75 Hz (automatic) 56 Hz to 76 Hz (automatic)
Maximum preset
resolution
1366 x 768 at 60 Hz 1600 x 900 at 60 Hz
Electrical Specifications
Model number Dell E1914H/E2014H monitor
Video input signals Analog RGB: 0.7 Volts +/- 5 %, 75 ohm input impedance
Synchronization input
signals
Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on
green)
AC input voltage /
frequency / current
100 VAC to 240 VAC/50 Hz or 60 Hz + 3 Hz/1.5 A
(Max.)
Inrush current 120 V: 30 A (Max.)
240 V: 60 A (Max.)
