Dell e2014h [53/81] Troubleshooting
![Dell e2014h [53/81] Troubleshooting](/views2/1166427/page53/bg35.png)
Troubleshooting 53
Synchronization
Problems
Screen is scrambled or
appears torn
•Reset the monitor to Factory
Settings.
•Perform Auto Adjust via OSD.
•Adjust Phase and Pixel Clock
controls via OSD.
•Perform monitor self-test
feature check to determine if
the scrambled screen appears
in self-test mode.
•Check for bent or broken pins
in the video cable connector.
•Restart the computer in the
safe mode.
Safety-Related Issues Visible signs of smoke
or sparks
•Do not perform any
troubleshooting steps.
•Contact Dell immediately.
Intermittent Problems Monitor malfunctions
on & o
•Ensure that the video cable
connecting the monitor to
the computer is connected
properly and is secure.
•Reset the monitor to Factory
Settings.
•Perform monitor self-test
feature check to determine if
the intermittent problem occurs
in self-test mode.
