34 Operating the Monitor
Input Source
(for E2014H
only)
Use the Input Source menu to select between dierent
video signals that may be connected to your monitor.
Input Source DVI - D
Dell E2014H Energy Use
Brightness / Contrast Auto Select
Other Settings
Personalize
Auto Adjust VGA
Energy Settings
Menu Settings
Color Settings
Display Settings
Resolution: 1024x768, 60Hz Maximum Resolution: 1600x900, 60Hz
Auto Select
Select Auto Select to scan for available input signals.
VGA
Select VGA input when you are using the analog (VGA)
connector. Push to select the VGA input source.
DVI-D
Select DVI-D input when you are using the Digital (DVI)
connector. Push to select the DVI input source.
