56 Troubleshooting
Distorted Sound Computer’s sound
card is used as the
audio source
•Clear any obstructions between
the Soundbar and the user.
•Confirm that the audio line-in
plug is completely inserted into
the jack of the sound card.
•Set all Windows volume
controls to their midpoints.
•Decrease the volume of the
audio application.
•Turn the Power/Volume knob
on the Soundbar counter-
clockwise to a lower volume
setting.
•Clean and re-seat the audio
line-in plug.
•Troubleshoot the computer’s
sound card.
•Test the Soundbar using
another audio source (For
example: portable CD player,
MP3 player).
•Avoid using an audio cable
extension or audio jack
converter.
Distorted Sound Other audio source is
used
•Clear any obstructions between
the Soundbar and the user.
•Confirm that the audio line-in
plug is completely inserted into
the jack of the audio source.
•Decrease the volume of the
audio source.
•Turn the Power/Volume knob
on the Soundbar counter-
clockwise to a lower volume
setting.
•Clean and reseat the audio line-
in plug.
Unbalanced Sound
Output
Sound from only one
side of Soundbar
•Clear any obstructions between
the Soundbar and the user.
•Confirm that the audio line-in
plug is completely inserted into
the jack of the sound card or
audio source.
•Set all Windows audio
balance controls (L-R) to their
midpoints.
•Clean and reseat the audio line-
in plug.
•Troubleshoot the computer’s
sound card.
•Test the Soundbar using
another audio source (For
example: portable CD player,
MP3 player).
