38 Operating the Monitor
Reset Display
Settings
Select this option to restore default display settings.
Energy
Settings
Other Settings
Personalize
Dell E1914H Energy Use
Brightness / Contrast Power Button LED On
Auto Adjust Reset Energy Settings
Color Settings
Display Settings
Energy Settings
Menu Settings
Resolution: 1024x768, 60Hz Maximum Resolution: 1366x768, 60Hz
Auto Adjust Reset Energy Settings
Input Source
Dell E2014H Energy Use
Brightness / Contrast Power Button LED On
Display Settings
Color Settings
Menu Settings
Energy Settings
Other Settings
Personalize
Resolution: 1024x768, 60Hz Maximum Resolution: 1600x900, 60Hz
Power Button
LED
Allows you to set the power LED indicator on or o to save
energy.
Reset Energy
Settings
Select this option to restore default Energy Settings.
