Dell alienware 15, a15-6366 [119/149] Post requisites

11 Turn the computer over.

Post-requisites

1 Replace the display assembly.

2 Replace the hinge covers.

3 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.

4 Replace the wireless card.

5 Replace the solid-state drives.

6 Replace the memory modules.

7 Replace the base panel.

119
