Dell alienware 15, a15-6366 [87/149] Procedure

Replacing the display bezel

WARNING: Before working inside your computer, read the

safety information that shipped with your computer and

follow the steps in

Before working inside your computer.

After working inside your computer, follow the instructions

in After working inside your computer. For more safety best

practices, see the Regulatory Compliance home page at

dell.com/regulatory_compliance.

Procedure

1 Follow the procedure from step 1 to step 2 in “Replacing the logo board”.

2 Connect the logo-board cable to the logo board and secure it with the

adhesive tape.

3 Slide the display-board cables into the logo board and press down on the

latches to secure the cables.

4 Carefully turn the display bezel over.

5 Align the display bezel with the display back-cover and gently snap the

display bezel into place.

Post-requisites

1 Replace the display assembly.

2 Replace the hinge covers.

3 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.

4 Replace the wireless card.

5 Replace the solid-state drives.

6 Replace the memory modules.

7 Replace the base panel.
