Replacing the touch pad

WARNING: Before working inside your computer, read the

safety information that shipped with your computer and

follow the steps in

Before working inside your computer.

After working inside your computer, follow the instructions

in After working inside your computer. For more safety best

practices, see the Regulatory Compliance home page at

dell.com/regulatory_compliance.

Procedure

1 Using the alignment posts on the palm-rest assembly, place the touch pad

on the palm-rest assembly.

2 Align the screw holes on the touch-pad bracket with the screw holes on the

palm-rest assembly and snap the touch-pad bracket into place.

3 Replace the screws that secure the touch-pad bracket to the palm-rest

assembly.

4 Adhere the touch-pad cable to the touch pad.

5 Slide the touch-pad cable and touch-pad buttons cable into the touch pad

and press down on the latches to secure the cables.

Post-requisites

1 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.

2 Replace the solid-state drives.

3 Replace the memory modules.

4 Replace the base panel.
