Replacing the keyboard

WARNING: Before working inside your computer, read the

safety information that shipped with your computer and

follow the steps in

Before working inside your computer.

After working inside your computer, follow the instructions

in After working inside your computer. For more safety best

practices, see the Regulatory Compliance home page at

dell.com/regulatory_compliance.

Procedure

CAUTION: Make sure that no cables are under the keyboard.

1 Slide the keyboard under the tabs on the palm-rest assembly.

2 Align the screw holes on the keyboard with the screw holes on the palm-

rest assembly.

3 Replace the screws that secure the keyboard to the palm-rest assembly.

4 Align the screw holes on the keyboard bracket with the screw holes on the

palm-rest assembly and snap the keyboard bracket into place.

5 Replace the screws that secure the keyboard bracket to the palm-rest

assembly.

6 Adhere the touch-pad cable and status-light cable to the keyboard bracket.

7 Slide the touch-pad cable and the status-light cable into the power-button

board and press down on the latches to secure the cables.

Post-requisites

1 Follow the procedure from step 5 to step 12 in “Replacing the palm rest”.

2 Replace the solid-state drives.

3 Replace the memory modules.

4 Replace the base panel.
