Replacing the palm rest

WARNING: Before working inside your computer, read the

safety information that shipped with your computer and

follow the steps in

Before working inside your computer.

After working inside your computer, follow the instructions

in After working inside your computer. For more safety best

practices, see the Regulatory Compliance home page at

dell.com/regulatory_compliance.

Procedure

1 Follow the procedure from step 1 to step 5 in "Replacing the touch pad”.

2 Follow the procedure from step 1 to step 3 in "Replacing the status-light

board”.

3 Follow the procedure from step 1 to step 4 in "Replacing the power-button

board”.

4 Follow the procedure from step 1 to step 7 in "Replacing the keyboard”.

5 Connect the power-button board cable to the system board.

6 Carefully turn the palm-rest assembly over and slide the keyboard cable,

keyboard-backlight cable, macro-keys cable, and macro-keys backlight

cable into the slot on the computer base.

7 Align the palm-rest assembly on the computer base and snap it into place.

8 Close the display and turn the computer over.

9 Replace the screws that secure the palm-rest assembly to the computer

base.

10 Slide the keyboard-backlight cable, keyboard cable, macro-keys cable, and

macro-keys backlight cable into the system board and press down on the

latches to secure the cables.

11 Route the keyboard-backlight cable, keyboard cable, and macro-keys cable

through the routing guides on the computer base.

Post-requisites

1 Replace the solid-state drives.

2 Replace the memory modules.

3 Replace the base panel.
