- 24 -
Hardware Installation
1-9 Internal Connectors
1) ATX_12V_2X4
2) ATX
3) ATX4P
4) CPU_FAN
5) SYS_FAN1/2/3/4
6) CPU_OPT
7) SATA_EXPRESS
8) SATA30/1/2/3/4/5
9) GSATA3 6/7
10) M.2
11) F_PANEL
12) F_AUDIO
13) SPDIF_O
14) F_USB30
15) F_USB1/F_USB2
16) COMA
17) TPM
18) CLR_CMOS
19) BAT
1
2
14
10
9
3
8
7
18
46
15
5
19
5115 1613 51712
8
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
