Ethernet Switch CLI Reference Guide
105
CHAPTER 23
GARP Commands
Use these commands to configure GARP.
23.1 GARP Overview
Switches join VLANs by making a declaration. A declaration is made by issuing a Join
message using GARP. Declarations are withdrawn by issuing a Leave message. A Leave All
message terminates all registrations. GARP timers set declaration timeout values.
23.2 Command Summary
The following section lists the commands for this feature.
Table 67 garp Command Summary
COMMAND DESCRIPTION M P
show garp Displays GARP information. E 3
garp join <100-65535> leave
<200-65535> leaveall <200-65535>
Configures GARP time settings (in milliseconds), including
the join, leave and leave all timers for each port. Leave Time
must be at least two times larger than Join Timer, and Leave
All Timer must be larger than Leave Timer.
C13
