Zyxel XS3900-48F [188/384] Table 112
![Zyxel XS3900-48F [188/384] Table 112](/views2/1168994/page188/bgbc.png)
Chapter 37 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
188
The following table describes the labels in this screen.
Table 112 Remote Switch LLDP information
LABEL DESCRIPTION
LLDP Remote Device
Information Detail
This contains the following information:
Local Port This is the local port number which receives the LLDPDU from the remote
Switch.
Chassis ID Subtype This displays how the chassis of the remote Switch is identified.
Chassis ID This displays the chassis ID of the remote Switch. The chassis ID is
identified by the chassis ID subtype.
Port ID Subtype This displays how the port is identified.
Port ID This is the ID of the remote Switch.
Time To Live This displays the time-to-live (TTL) multiplier of LLDP frames. The device
information on the neighboring devices ages out and is discarded when its
corresponding TTL expires. The TTL value is to multiply the TTL multiplier
by the LLDP frames transmitting interval.
Extended TLV Info 802.1
OUI (hex value)
The 802.1 organizationally specific TLVs start with the 24-bit
organizationally unique identifier (OUI) and a 1 byte organizationally
specific subtype followed by data. Each organization is responsible for
managing their subtypes.
Port VLAN ID This TLV displays the VLAN ID for the remote Switch.
DCBX Application
Priority
This TLV displays the priority given to FCoE traffic on the remote Switch.
DCBX ETS
Configuration
This TLV displays the willing bit, ETS capability and traffic class settings
configured by ETS on the remote Switch.
DCBX PFC
Configuration
This TLV displays the willing bit, PFC capability, and enabled priority list
configured by PFC on the remote Switch.
Extended TLV Info 802.3
OUI (hex value)
The 802.3 organizationally specific TLVs start with the 24-bit
organizationally unique identifier (OUI) and a 1 byte organizationally
specific subtype followed by data. Each organization is responsible for
managing their subtypes.
Max Frame Size This TLV displays the maximum transmission unit (MTU) sent by the
remote Switch.
