Chapter 81 VLAN IP Commands
Ethernet Switch CLI Reference Guide
324
81.3 Command Examples
See Section 3.4 on page 24 for an example of how to configure a VLAN management IP
address
ip address default-gateway
<ip-address>
Sets a default gateway IP address for this VLAN. C 13
no ip address default-
gateway
Deletes the default gateway from this VLAN. C 13
Table 190 vlan ip address Command Summary (continued)
COMMAND DESCRIPTION M P
