Chapter 37 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
186
The following table describes the labels in this screen.
This example shows local Switch (the Switch you’re accessing) LLDP information on a port.
Table 110 Local LLDP Information
LABEL DESCRIPTION
LLDP Global Local
Device Information
This contans the chassis ID subtype, chassis ID, and system name.
System Description This shows the firmware version number and date released.
System Capabilities
Supported
This shows what functionality the Switch supports.
System Capabilities
Enabled
This shows what functionality is enabled on the Switch.
Management Address This contains the management address subtype, interface number
subtype, interface number, and object identifier.
sysname# show lldp info local interface port-channel 2
LLDP Local Device Information Detail:
Local Port: 2
Port ID Subtype: local-assigned
Port ID: 2
Port Description:
Extended TLV Info 802.1 OUI (hex value) = 00-80-c2
-Port VLAN ID
-ID: 1
-DCBX Application Priority
- ether-type: fcoe Priority: 2
-DCBX ETS Configuration
-Willing Bit: False
-Max Traffic Classes: 3
-Priority-Group 2: Strict-priority, Priority-list:7
-Priority-Group 1: ETS Bandwidth 50%, Priority-list:3-6
-Priority-Group 0: ETS Bandwidth 50%, Priority-list:0-2
-DCBX PFC Configuration
-Willing Bit: True
-PFC capability: 8
-Priority enable list: 0-2
Extended TLV Info 802.3 OUI (hex value) = 00-12-0f
-MAC PHY Configuration & Status
-AN Supported: Y
-AN Enabled: Y
-AN Advertised Capability: 1000baseTFD
-Oper MAU type: 30
-Link Aggregation
-Capability: Y
-Status: N
-Port ID: 2
-Max Frame Size
-Frame Size: 1518
--------------------------------------------------
sysname#
