Zyxel XS3900-48F [319/384] This example configures ports 1 to 5 as fixed and untagged ports in vlan 2000
![Zyxel XS3900-48F [319/384] This example configures ports 1 to 5 as fixed and untagged ports in vlan 2000](/views2/1168994/page319/bg13f.png)
Chapter 80 VLAN Commands
Ethernet Switch CLI Reference Guide
319
• Some models enable or disable VLAN ingress checking on all the ports via the vlan1q
ingress-check command.
• Other models enable or disable VLAN ingress checking on each port individually via the
ingress-check command in the config-interface mode.
80.4 Command Examples
This example configures ports 1 to 5 as fixed and untagged ports in VLAN 2000.
This example deletes entry 2 in the static VLAN table.
This example shows the VLAN table.
Table 186 vlan1q ingress-check Command Summary
COMMAND DESCRIPTION M P
show vlan1q ingress-check Displays ingress check settings on the Switch. E 3
vlan1q ingress-check Enables ingress checking on the Switch. The Switch discards
incoming frames on a port for VLANs that do not include this
port in its member set.
C13
no vlan1q ingress-check Disables ingress checking on the Switch. C 13
Table 187 ingress-check Command Summary
COMMAND DESCRIPTION M P
interface port-channel <port-list> Enters config-interface mode for the specified port(s). C 13
ingress-check Enables ingress checking on the specified ports. The
Switch discards incoming frames for VLANs that do not
include this port in its member set.
C13
no ingress-check Disables ingress checking on the specified ports. C 13
sysname (config)# vlan 2000
sysname (config-vlan)# fixed 1-5
sysname (config-vlan)# untagged 1-5
sysname (config)# no vlan 2
sysname# show vlan
The Number of VLAN: 3
Idx. VID Status Elap-Time TagCtl
---- ---- -------- ------------ ------------------------
1 1 Static 0:12:13 Untagged :1-2
Tagged :
2 100 Static 0:00:17 Untagged :
Tagged :1-4
3 200 Static 0:00:07 Untagged :1-2
Tagged :3-8
