Ethernet Switch CLI Reference Guide
325
CHAPTER 82
VLAN Mapping Commands
Use these commands to configure VLAN mapping on the Switch. With VLAN mapping
enabled, the Switch can map the VLAN ID and priority level of packets received from a
private network to those used in the service provider’s network. The Switch discards the
tagged packets that do not match an entry in the VLAN mapping table.
You can not enable VLAN mapping and VLAN stacking at the same time.
82.1 Command Summary
The following section lists the commands for this feature.
Table 191 vlan mapping Command Summary
COMMAND DESCRIPTION M P
no vlan-mapping Disables VLAN mapping on the Switch. C 13
no vlan-mapping interface port-
channel <port> vlan <1-4094>
Removes the specified VLAN mapping rule. C 13
no vlan-mapping interface port-
channel <port> vlan <1-4094>
inactive
Enables the specified VLAN mapping rule. C 13
vlan-mapping Enables VLAN mapping on the Switch. C 13
vlan-mapping name <name>
interface port-channel <port>
vlan <1-4094> translated-vlan
<1-4094> priority <0-7>
Creates a VLAN mapping rule. C 13
vlan-mapping name <name>
interface port-channel <port>
vlan <1-4094> translated-vlan
<1-4094> priority <0-7> inactive
Disables the specified VLAN mapping rule. C 13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
vlan-mapping Enables VLAN mapping on the port(s). C 13
no vlan-mapping Disables VLAN mapping on the port(s). C 13
