Zyxel XS3900-48F [131/384] Command examples
![Zyxel XS3900-48F [131/384] Command examples](/views2/1168994/page131/bg83.png)
Chapter 29 IGMP Snooping Commands
Ethernet Switch CLI Reference Guide
131
29.2 Command Examples
This example enables IGMP snooping on the Switch, sets the host-timeout value to 30
seconds, and sets the Switch to drop packets from unknown multicast groups.
igmp-snooping querier-mode
<auto|fixed|edge>
Specifies whether or not and under what conditions the
port(s) is (are) IGMP query port(s). The Switch forwards
IGMP join or leave packets to an IGMP query port, treating
the port as being connected to an IGMP multicast router (or
server). You must enable IGMP snooping as well.
fixed: The Switch always treats the port(s) as IGMP query
port(s). Select this when you connect an IGMP multicast
server to the port(s).
auto: The Switch uses the port as an IGMP query port if the
port receives IGMP query packets.
edge: The Switch does not use the port as an IGMP query
port. The Switch does not keep any record of an IGMP router
being connected to this port. The Switch does not forward
IGMP join or leave packets to this port.
C13
no igmp-snooping filtering
profile
Prohibits the port(s) from joining any multicast groups if IGMP
filtering is enabled on the Switch.
C13
no igmp-snooping group-
limited
Disables multicast group limits. C 13
igmp-group-limited Enables the group limiting feature for IGMP snooping. You
must enable IGMP snooping as well.
C13
igmp-group-limited number
<number>
Sets the maximum number of multicast groups allowed.
number: 0-255
C13
no igmp-group-limited Disables multicast group limits. C 13
igmp-immediate-leave Enables the immediate leave function for IGMP snooping.
You must enable IGMP snooping as well.
C13
no igmp-immediate-leave Disables the immediate leave function for IGMP snooping. C 13
igmp-querier-mode
<auto|fixed|edge>
Specifies whether or not and under what conditions the
port(s) is (are) IGMP query port(s). The Switch forwards
IGMP join or leave packets to an IGMP query port, treating
the port as being connected to an IGMP multicast router (or
server). You must enable IGMP snooping as well.
fixed: The Switch always treats the port(s) as IGMP query
port(s). Select this when you connect an IGMP multicast
server to the port(s).
auto: The Switch uses the port as an IGMP query port if the
port receives IGMP query packets.
edge: The Switch does not use the port as an IGMP query
port. The Switch does not keep any record of an IGMP router
being connected to this port. The Switch does not forward
IGMP join or leave packets to this port.
C13
Table 79 interface igmp Command Summary (continued)
COMMAND DESCRIPTION M P
sysname(config)# igmp-snooping
sysname(config)# igmp-snooping host-timeout 30
sysname(config)# igmp-snooping unknown-multicast-frame drop
