NWA3000-N Series CLI Reference Guide
103
CHAPTER 17
File Manager
This chapter covers how to work with the NWA3000-N Series AP’s firmware, certificates,
configuration files, packet trace results, shell scripts and temporary files.
17.1 File Directories
The NWA3000-N Series AP stores files in the following directories.
17.2 Configuration Files and Shell Scripts Overview
You can store multiple configuration files and shell script files on the NWA3000-N Series AP.
When you apply a configuration file, the NWA3000-N Series AP uses the factory default
settings for any features that the configuration file does not include. Shell scripts are files of
commands that you can store on the NWA3000-N Series AP and run when you need them.
When you run a shell script, the NWA3000-N Series AP only applies the commands that it
contains. Other settings do not change.
You can edit configuration files or shell scripts in a text editor and upload them to the
NWA3000-N Series AP. Configuration files use a .conf extension and shell scripts use a .zysh
extension.
Table 56 FTP File Transfer Notes
DIRECTORY FILE TYPE
FILE NAME
EXTENSION
A
A. After you log in through FTP, you do not need to change directories in order to upload the firmware.
Firmware (upload only) bin
cert Non-PKCS#12 certificates cer
conf Configuration files conf
packet_trace Packet trace results (download only)
script Shell scripts .zysh
tmp Temporary system maintenance files and crash dumps for
technical support use (download only)
