Chapter 5 Interfaces
NWA3000-N Series CLI Reference Guide
41
The following table describes the commands available for VLAN interface managment. You
must use the
configure terminal command to enter the configuration mode before you
can use these commands.
netmask The network mask IP address. Enter a standard IPv4 IP address.
description Sets the description of the interface. You may use 0-511 alphanumeric
characters, underscores (
_), or dashes (-), but the first character cannot
be a number. This value is case-sensitive.
Table 13 Input Values for VLAN Interface Commands (continued)
LABEL DESCRIPTION
Table 14 Command Summary: VLAN Interface Profile
COMMAND DESCRIPTION
[no] interface config_interface Enters configuration mode for the specified interface. Use
the no parameter to remove the specified profile.
vlanid <1..4094> <tag|untag> Sets the interface’s VLAN identification number and sets
it to send tagged or untagged packets.
[no] ip address addr netmask Sets the interface’s IP address and subnet mask address.
Use the no parameter to remove these values from this
interface.
[no] ip address dhcp [metric <0..15>] Sets the interface to use the DHCP to acquire an IP
address. Enter the metric (priority) of the gateway (if any)
on this interface. The NWA3000-N Series AP decides
which gateway to use based on this priority. The lower the
number, the higher the priority. If two or more gateways
have the same priority, the NWA3000-N Series AP uses
the one that was configured first.
mtu <576..1500> Sets the maximum size of each data packet, in bytes, that
can move through this interface. If a larger packet arrives,
the NWA3000-N Series AP divides it into smaller
fragments.
no mtu Disables the mtu feature for this interface.
[no] ip gateway gateway [metric
<0..15>]
Enter the IP address of the gateway. The NWA3000-N
Series AP sends packets to the gateway when it does not
know how to route the packet to its destination. The
gateway should be on the same network as the interface.
Also enter the metric (priority) of the gateway (if any) on
this interface. The NWA3000-N Series AP decides which
gateway to use based on this priority. The lower the
number, the higher the priority. If two or more gateways
have the same priority, the NWA3000-N Series AP uses
the one that was configured first.
no vlan-id Removes the VLAN ID from the interface.
upstream <0..1048576> Sets the maximum amount of traffic, in kilobits per
second, the NWA3000-N Series AP can send through the
interface to the network.
no upstream Disables the upstream bandwidth limit.
downstream <0..1048576> Sets the maximum amount of traffic, in kilobits
per second, the NWA3000-N Series AP can receive
from the network through the interface.
no downstream Disables the downstream bandwidth limit.
