NWA3000-N Series CLI Reference Guide
135
CHAPTER 22
Maintenance Tools
Use the maintenance tool commands to check the conditions of other devices through the
NWA3000-N Series AP. The maintenance tools can help you to troubleshoot network
problems.
Here are maintenance tool commands that you can use in privilege mode.
Table 73 Maintenance Tools Commands in Privilege Mode
COMMAND DESCRIPTION
packet-trace [interface interface_name] [ip-
proto {<0..255> | protocol_name | any}] [src-
host {ip | hostname | any}] [dst-host {ip |
hostname | any}] [port {<1..65535> | any}]
[file] [duration <1..3600>] [extension-filter
filter_extension]
traceroute {ip | hostname}
Sends traffic through the specified interface with
the specified protocol, source address, destination
address, and/or port number.
If you specify
file, the NWA3000-N Series AP
dumps the traffic to
/packet_trace/
packet_trace_interface
. Use FTP to
retrieve the files (see Section 17.6 on page 107).
If you do not assign the duration, the NWA3000-N
Series AP keeps dumping traffic until you use Ctrl-
C.
Use the extension filter to extend the use of this
command.
protocol_name: You can use the name, instead
of the number, for some IP protocols, such as
tcp,
udp, icmp, and so on. The names consist of 1-16
alphanumeric characters, underscores (_), or
dashes (-). The first character cannot be a number.
hostname: You can use up to 252 alphanumeric
characters, dashes (-), or periods (.). The first
character cannot be a period.
filter_extension: You can use 1-256
alphanumeric characters, spaces, or '()+,/
:=?;!*#@$_%.- characters.
traceroute {ip | hostname} Displays the route taken by packets to the specified
destination. Use
Ctrl+c when you want to return
to the prompt.
[no] packet-capture activate Performs a packet capture that captures network
traffic going through the set NWA3000-N Series
AP’s interface(s). Studying these packet captures
may help you identify network problems.
The no command stops the running packet capture
on the NWA3000-N Series AP.
Note: Use the packet-capture
configure command to configure
the packet-capture settings before
using this command.
