Chapter 1 Command Line Interface
NWA3000-N Series CLI Reference Guide
11
Figure 2 Login Screen
Enter the user name and password at the prompts.
" The default login username is admin and password is 1234. The username
and password are case-sensitive.
1.2.2 Web Configurator Console
The Console allows you to use CLI commands from directly within the Web Configurator
rather than having to use a separate terminal program. In addition to logging in directly to the
NWA3000-N Series AP’s CLI, you can also log into other devices on the network through this
Console. It uses SSH to establish a connection.
" To view the functions in the Web Configurator user interface that correspond
directly to specific NWA3000-N Series AP CLI commands, use the CLI
Messages window (described in the User’s Guide) in tandem with this one.
Welcome to NWA3160-N
Username:
