Chapter 1 Command Line Interface
NWA3000-N Series CLI Reference Guide
16
1.4.1 Background Information
" See the User’s Guide for background information about most features.
This section provides background information about features that you cannot configure in the
web configurator. In addition, this section identifies related commands in other chapters.
1.4.2 Command Input Values
This section lists common input values for the commands for the feature in one or more tables
1.4.3 Command Summary
This section lists the commands for the feature in one or more tables.
1.4.4 Command Examples
This section contains any examples for the commands in this feature.
1.4.5 Command Syntax
The following conventions are used in this User’s Guide.
• A command or keyword in courier new must be entered literally as shown. Do not
abbreviate.
• Values that you need to provide are in italics.
• Required fields that have multiple choices are enclosed in curly brackets
{}.
• A range of numbers is enclosed in angle brackets
<>.
• Optional fields are enclosed in square brackets
[].
•The
| symbol means OR.
1.4.6 Changing the Password
It is highly recommended that you change the password for accessing the NWA3000-N Series
AP. See Section 13.2 on page 82 for the appropriate commands.
