ZyWALL USG Support Notes
136
All contents copyright (c) 2010 ZyXEL Communications Corporation.
Note: By default, Firewall blocks all the access except the traffic like VRRP,
IPSec ESP, IPSec AH, IPSec NATT, IPSec IKE.
A03. What’s difference between “Admin Service Control” and
“User Service Control” configuration in GUI menu System >
WWW?
