ZyWALL USG Support Notes
99
All contents copyright (c) 2010 ZyXEL Communications Corporation.
Step2. Go to Configuration > Object > Address, add address objects for Br1 local
subnet and Br2 local subnet for later use in IPSec VPN configuration.
Step3. Go to Configuration > VPN > IPSec VPN > VPN Gateway, add VPN phase1
rules for tunnels to Br1 and Br2.
To Br1:
My Address: WAN1 IP (172.25.27.140)
Peer Gateway Address: Br1 WAN IP (172.25.27.90)
