DSL-500 ADSL Router User’s Guide
Standards Compatability and Compliance
The DSL-500 complies with or is compatible with the following standards as
recognized by their respective agencies.
♦ ITU G.994.1 (G.Hs Auto-handshake) compliant
♦ ITU G.992.1 (G.dmt Full-rate ADSL) compliant
♦ ITU G.992.2 (G.lite “Splitterless ADSL”) compliant
♦ ITU-T Rec. I.361 compliant
♦ ITU-T Rec. I.610 compliant
♦ Compatible with all T1.413 issue 2 (full rate DMT over analog POTS), and
CO DSLAM equipment
♦ RFC 1483 Multi-protocol over ATM “Bridged Ethernet” compliant
♦ RFC 2364 PPP over ATM compliant
♦ RFC 2516 PPP over Ethernet compliant
♦ RFC 1334 PPP Authentication Protocol compliant
♦ RFC 1994 Challenge Handshake Authentication Protocol compliant
♦ RFC 791 Internet Protocol compliant
♦ RFC 826 Address Resolution Protocol compliant
♦ RFC 950 Internet Control Message Protocol compliant
♦ RFC 1631 Net Address Translator compliant
♦ Supports RFC 2131 and RFC 2132 DHCP functions including: automatic
assignment of IP address, use of subnet mask and default gateway and
provision of DNS server address for all hosts
♦ IEEE 802.3 compliant
♦ IEEE 802.3u compliant
♦ IEEE 802.1d compliant
♦ Supports RIP v1 and RIP v2
♦ Supports Static Routing
♦ Supports ATM Forum UNI V3.1 PVC
♦ Minimum ATM cell forwarding rate: 640 Kbps
♦ Supports up to eight simultaneous ATM virtual connections
4
