DSL-500 ADSL Router User’s Guide
Additional Requirements
You will need a PC (referred to in this guide as the Manager PC) to set up and
use the Router. In addition, it will be necessary to configure the device using
information provided by your ADSL service provider. This information is used to
establish the parameters of the ADSL connection and identify the Router on the
WAN. The requirements for the PCs on your LAN are summarized below.
PC WORKSTATION REQUIREMENTS
You can use the Router with PCs that meet the conditions discussed here.
Operating System
The web-based management software can be used on PCs running one of the
following operating systems:
Microsoft Windows 95 Windows 98 SE Windows 2000
Windows 98 Windows Me Windows NT 4.x
Web Browser
Any common web browser such as Microsoft Internet Explorer or Netscape
Navigator can be used to configure the Router using the embedded web-based
management software.
Ethernet Adapter
All PCs using the Router for Internet access, including the Manager PC, must
have an Ethernet NIC (Network Interface Card) installed. Each computer on the
internal network must have TCP/IP Protocol enabled. If you have an existing
Ethernet set up, the PCs should already meet this requirement.
ADSL SETTINGS
Each ADSL client on a DSL network has a unique integer pair used by the DSL
network managers to provide dedicated bandwidth on the ATM network
backbone. This pair of numbers is sometimes called the VPI/VCI pair.
The Virtual Path Identifier (VPI) and a Virtual Channel Identifier (VCI)
must be entered during the configuration process.
ADSL SETTINGS
VPI value: VCI value:
11
