DSL-500 ADSL Router User’s Guide
General
Standards: ITU G.992.1 (G.dmt)
ITU G.992.2 (G.lite)
ITU G.994.1 (G.Hs)
ITU-T Rec. I.361
ITU-T Rec. I.610
IEEE 802.3
IEEE 802.3u
IEEE 802.1d
RFC 791 (IP Routing)
RFC 792 (UDP)
RFC 826 (ARP)
RFC 1058 (RIP 1)
RFC 1389 (RIP 2)
RFC 1213 compliant
RFC 1483 (Bridged
Ethernet)
RFC 1577 (IP over
ATM)
RFC 1661 (PPP)
RFC 1994 (CHAP)
RFC 1334 (PAP)
RFC 2364 (PPP over
ATM)
RFC 1631 (NAT)
RFC 1877 (Automatic
IP assignment)
RFC 2516 (PPP over
Ethernet)
Supports RFC 2131
and RFC 2132 (DHCP)
Compatible with all
T1.413 issue 2 (full
rate DMT over analog
POTS), and CO
DSLAM equipment
Supports ATM Forum
UNI V3.1 PVC
configuration
Physical and Environmental
DC inputs:
Power
Adapter:
Input: 120V AC 60Hz 24W
Output: 12V DC 1.0 A
Power
Consumption:
10 Watts (max)
Operating
Temperature:
0° to 40° C (32° - 104° F)
Humidity: 5 to 95% (non-condensing)
Dimensions: 215 mm x 163 mm x 45 mm
Weight: 455 gm (1 lb.)
EMI:
CE Class B FCC Class B
Safety: UL/CUL TUV
Reliability: Mean Time Between Failure (MTBF) min. 4 years
57
