▶DRAM Timing Mode [Auto]

Selects the memory timing mode.

[Auto] DRAM timings will be determined based on SPD (Serial Presence

Detect) of installed memory modules.

[Link] Allows user to congure the DRAM timing manually for all memory

channel.

[UnLink] Allows user to congure the DRAM timing manually for respective

memory channel.

▶Advanced DRAM Conguration

Press <Enter> to enter the sub-menu. This sub-menu will be activated after setting

[Link] or [Unlink] in “DRAM Timing Mode”. User can set the memory timing for each

memory channel. The system may become unstable or unbootable after changing

memory timing. If it occurs, please clear the CMOS data and restore the default

settings. (Refer to the Clear CMOS jumper/ button section to clear the CMOS data,

and enter the BIOS to load the default settings.)

▶DRAM Training Conguration*

Press <Enter> to enter the sub-menu. Enables or disables the various training ways of

DRAM. The system may become unstable or unbootable after changing these items

in this sub-menu. If it occurs, please clear the CMOS data and restore the default

settings. (Refer to the Clear CMOS jumper/ button section to clear the CMOS data,

and enter the BIOS to load the default settings.)

▶Memory Fast Boot [Auto]

Enables or disables the initiation and training for memory every booting.

[Auto] This setting will be congured automatically by BIOS.

[Enabled] Memory will completely imitate the archive of rst initiation and rst

training. After that, the memory will not be initialed and trained when

booting to accelerate the system booting time.

[Disabled] The memory will be initialed and trained every booting.

< Voltage Setting >

▶SVID Communication [Auto]*

Enables or disables SVID (Serial Voltage Identication) support.

[Auto] This setting will be congured automatically by BIOS.

[Enabled] PWM phase will be changed dynamically according to the CPU SVID

(Serial Voltage Identication).

[Disabled] Disables SVID (Serial Voltage Identication) support.

▶VCCIN Voltage [Auto]

Sets the CPU input voltage. The CPU input voltage is the CPU power source that is

shared with components of the CPU.
