Chapter 1
1-2
Getting Started
Packing Contents
* These pictures are for reference only and may vary without notice.
SATA Cable
Optional Accessories
M-Connector
Drivers & Utilities
Disc
Motherboard
User Guide
I/O Shield
Motherboard
USB 3.0 Bracket
SOCKETAM3
