Chapter 1
1-17
Getting Started
Expansion Slots
This motherboard contains numerous slots for expansion cards, such as discrete
graphics or audio cards.
PCI_E1~4: PCIe Expansion Slots
The PCIe slot supports the PCIe interface expansion card.
PCIe x1 Slot
PCIe x16 Slot
PCI1~2: PCI Expansion Slots
The PCI slot supports additional LAN, SCSI, USB, and other add-on cards that comply
with PCI specications.
PCI Slot
Important
When adding or removing expansion cards, always turn o the power supply and
unplug the power supply power cable from the power outlet. Read the expansion
card’s documentation to check for any necessary additional hardware or software
changes.
