MSI 970a sli krait edition [72/88] Chapter 3
![MSI 970a sli krait edition [72/88] Chapter 3](/views2/1174528/page72/bg48.png)
Chapter 3
3-18
BIOS Setup
OC PROFILE
▶Overclocking Prole 1/ 2/ 3/ 4/ 5/ 6
Overclocking Prole 1/ 2/ 3/ 4/ 5/ 6 management. Press <Enter> to enter the sub-
menu.
▶Set Name for Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Names the current overclocking prole.
▶Save Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Saves the current overclocking prole.
▶Load Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Loads the current overclocking prole.
▶Clear Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Clears the current overclocking prole.
▶OC Prole Save to USB
Saves OC prole to the USB ash disk drive. The USB ash disk should be FAT32
format only.
▶OC Prole Load from USB
Loads OC prole from the USB ash disk drive. The USB ash disk should be FAT32
format only.
