Chapter 1
1-4
Getting Started
Motherboard Specications
CPU Support ■ Supports AMD
®
FX
TM
/ Phenom
TM
II/ Athlon
TM
II and Sempron
TM
processors for the AM3/ AM3+ socket
Hypertransport ■ HyperTransport™ 3.0, supports up to 4.8 GT/s
Chipset ■ AMD
®
970 & SB950
Memory
Support
■ 4x DDR3 memory slots supporting up to 32GB
■ Supports DDR3 2133(OC)/ 1866/ 1600/ 1333/ 1066 MHz
■ Dual channel memory architecture
Expansion
Slots
■ 2x PCIe 2.0 x16 slots
- PCI_E2 supports up to PCIe 2.0 x16 speed
- PCI_E4 supports up to PCIe 2.0 x8 speed
■ 2x PCIe 2.0 x1 slots
■ 2x PCI slots
Multi-GPU
Support
■ Supports 2-Way NVIDIA
®
SLI
TM
Technology
■ Supports 2-Way AMD
®
CrossFire
TM
Technology*
* Supports Windows 7 and Windows 8/ 8.1
Storage ■ AMD
®
SB950 Chipset
- 6x SATA 6Gb/s ports
- Supports RAID 0, RAID1, RAID5 and RAID 10
USB ■ AMD
®
SB950 Chipset
- 12x USB 2.0 ports (6 ports on the back panel, 6 ports
available through the internal USB 2.0 connectors)
■ AsMedia ASM1042A
- 2x USB 3.0 ports available through the internal USB 3.0
connector*
■ AsMedia ASM1142
- 2x USB 3.1 ports on the back panel*
* These USB 3.0/ 3.1 ports do not support M-Flash recovery function.
Audio ■ Realtek
®
ALC887 Codec
- 7.1-Channel High Denition Audio
LAN ■ 1x Realtek
®
8111E Gigabit LAN
Back Panel
Connectors
■ 1x PS/2 keyboard port
■ 1x PS/2 mouse port
■ 6x USB 2.0 ports
■ 2x USB 3.1 ports
■ 1x LAN (RJ45) port
■ 6x audio jacks
